Reyes Machinery
The PTD series of centrifuges can be used for extracting and filtering centrifuges for cannabis and other plants. The series of centrifuges extract the active ingredients in plants through a built-in program, which is single-handed, easy to use and large in capacity. The machine adopts a closed structure, and the seal is sealed with PTEF; the explosion-proof motor, frequency converter, PLC, touch screen and other devices can be used to achieve the sealed explosion-proof requirements.
• Explosion-proof Motor
• Viton Seals
• Touch screen panel with PLC program
• Inverter control box
• On spot ex button
• Closed type filter bags
• Tri clamp fittings for feed and drain port
• Drum without curl inward Standard Features 304 and 316L Sanitary Stainless Steel Constructio Low temperature rating:-70℃
| Model | Drum diameter (mm) |
Drum height (mm) |
Volume (L) |
Revolving speed (r/min) |
Motor Power (KW) |
Size (mm) |
Weight (KG) |
| PTD-15 | 300 | 250 | 15 | 2000 | 1.1 | 1100*550*1020 | 230 |
| PTD -25 | 300 | 350 | 25 | 2000 | 1.5 | 1100*600*1020 | 265 |
| PTD -45 | 450 | 300 | 45 | 1500 | 2.2 | 1400*850*1080 | 400 |
| PTD -60 | 450 | 400 | 60 | 1500 | 3 | 1400*850*1080 | 470 |
| PTD -85 | 600 | 300 | 85 | 1250 | 3 | 1500*900*1080 | 970 |
| PTD -115 | 600 | 400 | 115 | 1250 | 4 | 1500*900*1100 | 1000 |
| PTD-145 | 600 | 500 | 145 | 1250 | 5.5 | 1500*900*1150 | 1030 |
