Product Details

LWS oil water 3 phase decanter centrifuge is widely used in chemical industry, light industry, medicine, food, paper making, mining and other industries

Dewatering and thickening of sludge form municipal and industrial waste water, such as : municipal sludge, paper mill sludge, starch sludge, steel mill sludge, printing and dyeing mill sludge, water works sludge, pharmaceutical sludge, PVC sludge, sewage desulfurization sludge, grain stillage, power plant ash sludge, dairy sludge, beer sludge, drilling mud, electroplating liquid, fermented liquid manure, oil refining sludge, soap sludge, leather sludge, and other types of sludge.

• Chemical or pharmaceutical products such as: butane dicarboxylic acid, alum, aluminum hydroxide, ammonium hydrogen carbonate, ammonium nitrate, ammoniumsulphate,anthracene,antibiotics,bariumchloride,bariumcarbonate,barium sulphate, benzene, blood products, blue vitriol, borax, boric acid, calcium carbonate, calcium citrate, calcium hydroxide, calcium nitrate, calcium oxalate, casein, cellulose, chrome yellow, clay, methyl cellulose, corundum, corn plum mule, cooking oil, processed fish, mirabilite, glutamate, hops, pesticide diatomaceous earth, herbicides, tartaric acid, sodium sulphate, sodium phosphate, sodium nitrate, carbon black and others materials.
• Mineral oil, waste oil, bilge sludge, lubricatingoil.
• Recovering of animal and vegetal basic products (oils/fats, starch, proteins) animal fat oil separation, like beef oil, pork oil, fish oil, chicken oil ect.
• Beverages (wine, beer,fruit,Fruit juice separation)
• Vinasse dewatering
• Sludge Oil Recovery
• Medical sludge dewatering
• Soy protein dehydration
• Plant oil clarification and separation
• Cosmetic clarification and separation
• Bleaching powder separation
• Coal tar separation

High Configuration LWS Decanter Centrifuge Features

• 3-phase AC motor for controlled torque starting via frequency converter, Dual Motors drive and Dual Variable Frequency Converter drive to realize the function of soft starting and slowstop;
• Bowl speed is adjustable via VFD to obtain the required G-force for optimized separation;
• Conveying speed is adjustable for optimized balance between liquid;
• Low personnel costs due to continuous and automatic operation;
• Highest g-force for higher solids output;
• Automatic adjustment of differential speed via VFD;
• Belts for both primary motor and secondary motor;
• All parts coming into contact with the product are made of stainless steel;
• Main machine parts such as the bowl and scroll conveyor are made of corrosion resistant ,Cemented carbide and high quality carbon steel or stainless steel, offering high maximum bowl speed and high centrifugal force;
• Wear-proof Ceramic, Tungsten Carbide tiles are sintered on the scroll conveyor;
• Centripetal pump ,Improve separation efficiency. More convenient on-site adjustment;
• Multiple safety protection: The overall electric protection (overload, default phase, over-torque of centrifuge protection, etc.); bowl speed and differential speed detection, over-vibration protection, motors overload and over heat protection, bearing temperature monitoring, conveyor torque protection;
• Advanced special structure, especially the design of BD board on the scroll conveyor, which makes the centrifuge have better performance, greater treating capacity and more efficient separating performance than the usual centrifuge. It’s also energy and additive saving, stably and reliably operating, and easy operating. The centrifuge is certified with ISO9001 qualitysystem;
• Guiding to select the suitable Decanter Centrifuge Equipment with customers' specific requirements;
• Our professional technicians would guide and train the customers to install, debug and maintain the Decanter Centrifugemachine;
• We accept customers' OEM order( According to customers' treating materials and specific requirement, we would re-design the structure to optimize the Decanter Centrifuge maximizingly);
• Some Models are specially designed with long range sedimentingarea.

Key Features of REYES Machinery (China) Decanter Centrifuge

• High Efficiency Separation: Equipped with high centrifugal force (1500–4000 G), our decanter centrifuge ensures thorough solid-liquid separation and 3-phase separation, removing fine particles and impurities effectively.
• Continuous Working Performance: No need for manual shutdown for slag discharge—realizes 24/7 automatic operation, saving labor costs and improving production efficiency for industrial applications.
• Low Sludge Moisture Content: The decanter centrifuge reduces sludge moisture to 40%–60%, significantly reducing sludge volume and transportation costs for sludge dewatering projects.
• Corrosion & Wear Resistant: Drum and screw are made of 316L stainless steel or duplex steel 2205, suitable for corrosive materials in chemical, oilfield, and wastewater treatment industries.
• Adjustable Differential Speed: Frequency conversion control for differential speed, adapting to different material concentrations and separation requirements (ideal for oil-water separation and sludge dewatering).
• Energy Saving & Environmental Friendly: Low power consumption, full sealed structure to prevent odor leakage and pollution, complying with global environmental standards.

Technical Parameter

Model	LWS355X1460	LWS420X1680	LWX530X2200	LWS650X2600
Bowl Diameter (mm)	360	420	530	650
Bowl Length (mm)	1460	1680	2200	2600
Max speed (Rpm)	3600	3500	3000	2600
L/D ratio	4	4	4	4
G-force	2576	2561	2415	2100
Capacity(m3/h)	2-10	3-25	5-45	6-65
Main Drive Motor(kw)	22	30	55	90/75
Auxiliary Drive Motor(kw)	7.5	11	22	30
Weight(kg)	2480	2900	4800	6800
Dimension(mm)	3400x950x1220	3900x1550x1230	4150x1650x1600	4570x1680x1839
Differential	Planet gear differential （2K-H two stages）
Differential speed	0.1-30r/min （Frequency conversion adjustment）
Electronic appliance control panel	Frequency conversion control cabinet
Main bearing lubricate	Grease lubricate （Full automatic lubrication）
Drum material	2304 /2205 duplex stainless steel
The above specification and parameters for reference only.

FAQ About Decanter Centrifuge

Below are the most frequently asked questions about decanter centrifuge, covering key concerns about solid-liquid separation, sludge dewatering, operation and maintenance.

Q1: What is a decanter centrifuge used for?

A decanter centrifuge is a professional industrial equipment mainly used for solid-liquid separation, 3-phase oil-water-solid separation, and sludge dewatering. It is widely applied in wastewater treatment, oilfield, chemical, food, and mining industries to clarify liquids, dewater sludge, and recover valuable materials like waste oil.

Q2: What is the difference between 2-phase and 3-phase decanter centrifuge?

A 2-phase decanter centrifuge is designed for simplesolid-liquid separation, separating solid particles from liquid efficiently. A3-phase decanter centrifuge can separate three components simultaneously—oil, water, and solid, which is perfect for oily sludge treatment, oilfield drilling mud separation, and waste oil recovery.

Q3: How efficient is the decanter centrifuge in sludge dewatering?

Our decanter centrifuge achieves high-efficiency sludge dewatering, reducing sludge moisture content to 40%–60%. This significantly reduces sludge volume, lowers transportation and disposal costs, and improves work efficiency for industrial sludge treatment projects.

Q4: What factors affect the separation effect of a decanter centrifuge?

The main factors affecting the separation effect include centrifugal factor (rotating speed), feed solid concentration, feed flow rate, material viscosity and temperature, and the design of the drum and screw. Proper adjustment of these factors ensures optimal solid-liquid separation and oil-water separation performance.

Q5: Is the decanter centrifuge easy to maintain and operate?

Yes, our decanter centrifuge features automatic 24-hour continuous working, no need for manual shutdown for slag discharge. It is equipped with frequency conversion control for easy operation, and all components are made of corrosion-resistant materials, reducing maintenance frequency and cost. We also provide professional guidance for operation and maintenance.

Q6: Can the decanter centrifuge be customized for specific needs?

Absolutely. We provide customized decanter centrifuge solutions according to your specific requirements, including capacity, separation type (2-phase or 3-phase), material compatibility, and solid-liquid separation precision, to meet the unique needs of different industries and projects.

REYES Machinery (China)

REYES Machinery (China) is a high-tech enterprise integrating consulting, R&D, production, sales and after-sales service for centrifuges, including decanter centrifuge, tubular centrifuge, disc separator and more. With ISO9001:2015 quality management system certification and EU CE certification, we have advanced production workshops, professional technical teams and perfect test measures to ensure each product meets international standards. Our decanter centrifuges are exported to Eurasia, America, Australia and other countries, winning trust with stable quality, cost-effective prices and timely after-sales service.
